Configuring with Web Based Management
6.10 "iFeatures" menu
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
404 Configuration Manual, 08/2018, C79000-G8976-C267-13
Note
This WBM page can only be configured with the following KEY
-PLUGs:
Access point: W780 iFeatures (MLFB 6GK5 907-8PA00)
Client: W740 iFeatures (MLFB 6GK5 907-4PA00)
When should iPCF be used?
Note
Use of iPCF with other iFeatures
iPCF and other iFeatures (e.g. iPCF
-MC, iPCF-
HT, iPRP) are not compatible with each other
and cannot be used at the same time on one device.
The use of iPCF is advisable particularly if you have a large number of nodes and want to
implement highly deterministic operation. This is necessary, for example with PROFINET or
other cyclic protocols. You will find a more detailed description of iPCF in the section
"Technical basics" in the section "iPCF / iPCF-HT / iPCF-MC (Page 57)".
The possible settings differ for access point and client. Both are described below:
