Siemens SCALANCE W788-1 M12

Configuring with Web Based Management
6.9 "Security" menu
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
396 Configuration Manual, 08/2018, C79000-G8976-C267-13
Description of the displayed boxes
The page contains the following boxes:
●
Interface
Select the required interface from the drop-down list. The available interfaces (Page 49)
depend on the device.
To select a VLAN interface, an IP interface must be configured.
Note
If you use a VLAN interface, the ACL rule applies to all ports that belong to
the VLAN.
●
Add Rule
In the drop-down list select the ACL rule to be assigned to the interface.
●
Add
To assign the ACL rule to the interface, click the "Add" button. The configuration is shown
in the table.
Note
An ACL rule with the content "deny any a
ny" must not be applied to outgoing frames.
●
Remove Rule
From the "Remove rule" drop-down list, select the ACL rule to be deleted.
●
Remove
To remove the ACL rule from the interface, click the "Remove" button.
The table has the following columns:
●
Rule Order
Shows the order of the ACL rules.
●
Rule Number
Shows the number of the ACL rule.
●
Protocol
Shows the protocol for which this rule is valid.
●
Protocol Number
Shows the protocol number.
●
Source IP
Shows the IPv4 address of the source.
●
Source Subnet Mask
Shows the subnet mask of the source.
●
Dest IP
Shows the IP address of the destination.
●
Dest. Subnet Mask
Shows the subnet mask of the destination.
