SCALANCE X-400 extender modules
Compact Operating Instructions, 04/2013, A5E00367421-10
35
Technical specifications
6
6.1 Extender module EM495-8 - technical specifications
Interfaces
Connection of end devices or network segments
over twisted pair
8 x RJ-45 jacks (10/100 Mbps)
All electrical ports support
autonegotiation and autocrossover.
Power consumption < 0.5 W
Permitted cable lengths
TP cable length With TP cord up to 10 m, with FastConnect
cabling system up to 100 m.
Permitted environmental conditions / EMC
Operating temperature:
• For product versions 01 to 02
• As of product version 03
0 °C through + 60 °C
- 40 °C through + 70 °C
Storage/transport temperature – 40°C through + 80°C
Relative humidity in operation < 95% (no condensation)
Operating altitude Max. 2000 m
RF interference level EN 55081 Class A
Immunity EN 61000-6-2: 2001
Construction
Dimensions (W x H x D) 86 x 145 x 112.4 mm
Weight 560 g
Degree of protection IP20
