Technical specifications
Weight 375 g
Installation options Installation on a DIN rail
Mean time between failure (MTBF)
MTBF (EN/IEC 61709; 40 °C) > 80 years
Attachment to Industrial Ethernet
Properties
Quantity 16
Connector RJ45 jack
Properties Half/full duplex, MDI‑X pinning
Transmission speed 10 / 100 Mbps
7.5 Technical specifications of the SCALANCE XB124
The following technical specifications apply to the SCALANCE XB124.
Technical specifications
Electrical data
Power supply Rated voltage 24 V AC/VDC
Voltage range 19.2 to 28.8 V AC/VDC Safety Extra Low
Voltage (SELV)
Design Terminal block, 3 terminals
Property Implemented redundantly
Current consumption At 24 V AC 450 mA
At 24 V DC 300 mA
Effective power loss At 24 V AC 10.8 VA
At 24 V DC 7.2 W
Fusing F 2.5 A / 125 V
Permitted ambient conditions
Ambient temperature During operation up to 3000 m 0 ℃ to +60 ℃
During storage -40 ℃ to +85 ℃
During transportation -40 ℃ to +85 ℃
Relative humidity During operation at 25 ℃ ≤ 95 % no condensation
Housing, dimensions and weight
Design compact
Housing material Polycarbonate (PC-GF10)
Degree of protection IP20
Dimensions (W x H x D) 120 x 117 x 109 mm
Weight 535 g
Installation options Installation on a DIN rail
Technical specifications
7.5 Technical specifications of the SCALANCE XB124
SCALANCE XB-100
38 Operating Instructions, 02/2019, C79000-G8976-C473-03
