Description of the device
3.4 SET button
SCALANCE XC-100
18 Operating Instructions, 06/2016, C79000-G8976-C415-02
1
LEDs flash at 5 Hz The currently set fault mask is displayed. The LEDs of the monitored
ports flash.
If no fault mask is set, all port LEDs flash one after the other.
If you release the button in phase 1, this has no effect.
2 LEDs flash at 2.5 Hz The current status is displayed.
• The LEDs of the ports at which there is currently a link flash.
If you release the button in phase 2, this has no effect.
3
This new status is adopted and stored as the new fault mask in phase 3.
LEDs flashing If you release the SET button while the LEDs are still flashing, storing is
LEDs lit If you release the SET button as soon as the LEDs light up, the current
settings will be stored.
The stored status is displayed.
• The monitored ports are indicated by statically lit LEDs.
• The monitored power supply is indicated by statically lit LEDs.
Note
If an empty fault mask is set or needs to be set, the 2 port LEDs flash alternately. If the fault
mask is empty, no port is
monitored.
If the link is lost at a monitored port or a monitored power supply is lost, this is signaled as
follows:
● the red fault LED lights up
● the signaling contact is opened
