Technical specifications
7.5 Mechanical stability (in operation)
SCALANCE XC-100
46 Operating Instructions, 06/2016, C79000-G8976-C415-02
Technical specifications
Switching properties
Aging time
45 seconds
Max. number of learnable MAC ad-
dresses
2048
Response to LLDP frames
Blocking
Response to spanning tree BPDU
frames
Forwarding
CoS acc. to IEEE 802.1Q
Yes
QoS priority queues
4
IEEE 802.1Q tags (VLAN ID, priority)
transparent forwarding
Yes
Maximum frame size
1532 bytes
Forwarding of PRP frames (Parallel
Redundancy Protocol)
Yes
7.5
Mechanical stability (in operation)
Mechanical stability (in operation)
Device
IEC 60068-2-27 shock
IEC 60068-2-6 vibration
15 g, 11 ms duration
6 shocks per axis
10 - 58 Hz: 0.075 mm
85 - 150 Hz: 1 g
1 octave/min, 20 sweeps
SCALANCE XC106-2
●
●
SCALANCE XC108
●
●
SCALANCE XC116
●
●
SCALANCE XC124
●
●
