Siemens SCALANCE XC-100 User Manual

Technical specifications
7.1 Technical specifications SCALANCE XC106-2
SCALANCE XC-100
40 Operating Instructions, 06/2016, C79000-G8976-C415-02
Technical specifications
Signaling contact
Quantity
1
Design
Terminal block, 2 terminals
Permitted voltage range
24 VDC
Load capability
max. 100 mA
Permitted ambient conditions
Ambient temperature
During operation up to 2000 m
-40 °C to +70 °C
During storage
-40 ℃ to +85 ℃
During transportation
-40 ℃ to +85 ℃
Relative humidity
During operation at 25 ℃
≤ 95 % no condensation
Housing, dimensions and weight
Design
compact
Housing material
Polycarbonate (PC-GF10)
Degree of protection
IP20
Dimensions (W x H x D)
60 x 147 x 125 mm
Weight
500 g
Installation options
• Wall mounting
• Installation on a DIN rail
• Mounting on an S7-300 standard rail
• Mounting on an S7-1500 standard rail
Mean time between failure (MTBF)
MTBF (EN/IEC 61709; 40 °C)
> 84.92 years
Switching properties
Aging time
45 seconds
Max. number of learnable MAC
addresses
2048
Response to LLDP frames
Blocking
Response to spanning tree BPDU
frames
Forwarding
CoS acc. to IEEE 802.1Q
Yes
QoS priority queues
4
IEEE 802.1Q tags (VLAN ID, priori-
ty)
transparent forwarding
Yes
Maximum frame size
1532 bytes
Forwarding of PRP frames (Parallel
Redundancy Protocol)
Yes
