Siemens SED2 User Manual

AOP Overview
Siemens Building Technologies 3
AOP Overview
AOP Menu Structure
The menus available on the AOP display depend on the currently active operating mode. The
following diagram shows the menu structure when the AOP is in either the Local or Master
operating mode.
OPERATE
DIAGNOSTICS
PARAMETERS
MODE
UPREAD
DOWNLOAD
LANGUAGE
SETUP
TIMER
SELECT GROUP:
ALL PARAMETERS
NOT DEFINED
INVERTER
MOTOR
SPEED SENSOR
TECHNICAL APPLICATION/UNIT
NOT DEFINED
COMMANDS, BIN I/O
ADC AND DAC
NOT DEFINED
SETPOINT CHANNEL/RFG
NOT DEFINED
DRIVE FEATURES
MOTOR CONTROL
NOT DEFINED
NOT DEFINED
NOT DEFINED
NOT DEFINED
NOT DEFINED
NOT DEFINED
COMMUNICATION
ALARM/WARNING/MONITOR
TECHNICAL CONTROLELR
BACKLIGHTING
SCREEN CONTRAST
LARGE NUMBERS
CURSOR TYPE
START HELP
WELCOME TEXT
USER DEFINED TEXT
PARAMETER SET NAMES
SET TIME/DATE
AOP RESET
ENGLISH
GERMAN
FRENCH
SPANISH
ITALIAN
LOCAL (1 Drive)
MASTER (>1 Drive)
INTERNAL
SLAVE
PC MODE
MAIN MENU (Local and Master Modes)
