Siemens SENTRON 3WL10 User Manual

Circuit diagrams
10.1 Circuit diagrams of accessories
3VA27 molded case circuit breakers & 3WL10 air circuit breakers
Manual, 10/2018, L1V30499596002-01
253
10.1.2
Spring charging motor (MO), spring charged signaling switch (S21), remote
reset magnet (RR)
3WL10 / 3VA27 SE
10.1.3
Tripped signaling switch, toggle operating mechanism MCCB (TAS)
3VA27 toggle
