Circuit diagrams
10.1 Circuit diagrams of accessories
3VA27 molded case circuit breakers & 3WL10 air circuit breakers
Manual, 10/2018, L1V30499596002-01
263
10.1.16
Auxiliary switch AUX 15, external
3WL10/3VA27 SE + 3VA27 toggle
10.1.17
Optional voltage input, external neutral for the metering function of a 3-pole
circuit breaker
3WL10 / 3VA27 SE + 3VA27 toggle
