Technical data
36
Dimensions 3.9” x 4.3” x 2.9” (H x W x D), without CF card / plug
Weight approx. 1 LB
Installation top hat rail DIN EN 500 22
Ambient Temperature
32 ... 131° F
Air humidity 0 - 95%, not condensing
Protection class enclosure IP40 / screw terminals IP20
Power supply 10..60 V DC, 5% ripple
50..80 V DC, 5% ripple
Max. current consumption without modem:
at 12V: approx. 420mA
at 24V: approx. 210mA
with analog modem:
at 12V: approx. 600mA
at 24V: approx. 300mA
with ISDN modem:
at 12V: approx. 460mA
at 24V: approx. 230mA
Power consumption without modem:
max. 5W
with Analog modem:
max. 7W
with ISDN modem:
max. 5.5W
Relay outputs DC: 1A / 30V
AC: 0.5A / 125V
