PC Adapter USB
A5E00166353-02
4-1
4 Hardware Design of the PC Adapter USB
4.1 Connections
The following connections are available on the PC Adapter USB:
USB interface
LEDs:
USB
Power
MPI
MPI/DP
interface
13.05.2003
3.05.200313.05.200313.05.2003
