PC Adapter USB on the MPI/DP Network
PC Adapter USB
6-2 A5E00166353-02
6.3 Use in a Network System
The following illustration shows the connection in a S7 system network (MPI/DP
network with 2 or more network nodes).
S7x
S7y
PROFIBUS bus cable
Adapter
4
)
3
)
4
)
PROFIBUS bus connector
3)
Bus connector with PG socket
Once you have completed the installation and configuration of the PG/PC interface,
you can communicate with the automation system using your SIMATIC software
package.
13.05.2003
3.05.200313.05.200313.05.2003
