Digital electronic module 2RO NO DC24..120V/5A, AC24..230V/5A (6ES7132-4HB01-0AB0)
Manual, 04/2007, A5E01077282-01
7
Properties
1
1.1 Digital electronic module 2RO NO DC24..120V/5A, AC24..230V/5A
(6ES7132-4HB01-0AB0)
Properties
● Digital electronic module with two relay outputs
● Output current
5 A per output
● Rated load voltage DC up to 120 V / AC to 230 V
● Suitable for solenoid valves, DC contactors, and indicator lights
● Isolated from the supply voltage
● Extended temperature range from 0 to 55 °C with vertical installation
CAUTION
The rated power supply voltage of the 2RO NO DC24..120V/5A, AC24..230V/5A is
24 VDC. The 2RO NO DC24..120V/5A, AC24..230 V/5A must be in a 24 VDC potential
group only (from the power module).
General terminal assignment
Note
Terminals 4, 8, A4, A8, A3 and A7 are only available at specified terminal modules.
Terminal assignment for 2RO NO DC24..120V/5A, AC24..230V/5A (6ES7132-4HB01-0AB0)
Terminal Assignment Terminal Assignment Notes
1 13 5 23
2 14 6 24
3 14 7 24
4 n.c. 8 n.c.
A4 AUX1 A8 AUX1
A3 AUX1 A7 AUX1
• 13, 14: Normally open contact, Channel 0
• 23, 24: Normally open contact, Channel 1
• n.c.: Not connected (max. 30 V DC can be connected)
• AUX1: Protective-conductor terminal or potential bus (freely usable
up to 230 VAC)
