Diagnostic blocks in S7 standard mode and in the redundancy mode
The table below shows the lengths of the diagnostics blocks and their offset in the diagnostics
frame.
Table 11-1 Length and offset of the diagnostic blocks in S7 standard mode and in redundancy mode
Diagnostic block Length in bytes Offset in the non-redun‐
dancy mode
Offset in the redundancy
mode
Default diagnostics 6 0 0
Identifier-related diagnostics 6 6 6
Module status 13 12 12
Status message 38 25 25
H status 8 - 63
Interrupt section (max. 63 *) (63 *) (71 *)
Total length 63
(max. 126 *)
71
(max. 134 *)
* only if interrupts are reported
11.2.2 Structure of the diagnostic blocks
11.2.2.1 Default diagnosis
Format of the default diagnostics
The default diagnostics consists of 6 bytes and is subdivided as follows:
%\WH
%\WH
%\WH
%\WH
%\WH
%\WH
6WDWLRQVWDWXVHVbbWRb
0DVWHU352),%86DGGUHVV
'HYLFHLGHQWLILHU
Figure 11-1 Format of the default diagnostics
Alarm, error, and system messages
11.2 Diagnostics of the Compact FF Link
Compact FF Link
Operating Instructions, 03/2015, A5E35651552-AA 65
