ET 200PA SMART+ distributed I/O system
A5E52951242-AA, 07/2023
9
Fastening/unfastening components
Component
Fastening/unfastening
Tightening torque
Rail Drill hole: 6.5 mm TORX T15 screwdriver or
1.5 Nm
Connecting functional
grounding to the rail
M6 screw. M6 nut and bolts
4 Nm
IM carrier module
Screws are located in the IM carrier
module
1.5 Nm
Carrier module
(slots for I/O modules)
Screw is located in the carrier
module
Note:
4 fixing screws on the carrier
module 8x
4.5 mm blade width
1.5 Nm
Terminal block
Plug-in / lever out with a
screwdriver (see System Manual ET
200PA SMART+ distributed I/O
system
(
https://support.industry.siemens.c
om/cs/in/en/view/109822231))
None
Interface module
Snap-in / release with screwdriver
(see System Manual ET 200PA
SMART+ distributed I/O system
(
https://support.industry.siemens.c
om/cs/in/en/view/109822231))
width
None
I/O module
Snap-in / release buttons
None
BusAdapter
Screw is located in the BusAdapter
0.25 Nm
Server module
Click mounting
None
Power bus cover
Click mounting
None
Wires on the terminal block
(see System Manual ET
200PA SMART+ distributed
I/O system
(
https://support.industry.sie
mens.com/cs/in/en/view/10
9822231))
Spring release
(see System Manual ET 200PA
SMART+ distributed I/O system
(
https://support.industry.siemens.c
om/cs/in/en/view/109822231))
3.5 to 4.5 mm blade width
None
Shield connection for
process cable in the
terminal block (shield
terminal)
Screw is located in the shield
terminal
Note: Cable with max. 7 mm
each
3.5 to 4.5 mm blade width
0.5 Nm
Fasten D-SUB connector to
D-Sub terminal block
Screw is located in the D-SUB
connector
0.4 Nm
