Siemens SIMATIC ET 200PA SMART+ User Manual

ET 200PA SMART+ distributed I/O system
10 A5E52951242-AA, 07/2023
Cables with and without ferrule
Rule for ...
Interface module (supply
voltage)
Terminal blocks
(push-in terminal)
Permitted cable cross-sections for solid cables
0.2 to 2.5 mm
2
AWG
*
: 24 to 13
Permitted cable cross-
sections for flexible
cables
Without ferrule
0.2 to 2.5 mm
2
AWG
*
: 24 to 13
AWG*: 24 to 14
With ferrule (with plastic
sleeve)
***
0.25 mm to 1.5 mm
2**
0.14 mm to 1.5 mm
2
AWG
*
: 24 to 16
AWG
*
: 26 to 16
With TWIN ferrule
***
0.5 mm to 1 mm
2
0.5 to 0.75 mm
2
(see below)
Stripped length of the cables
•
Ferrules for single cores: 8 to 10 mm
• Twin ferrules: 12 to 14 mm
Wire end ferrules in accordance with DIN 46228
with plastic sleeve
***
8 and 10 mm long
* AWG: American Wire Gauge
** Ferrules without plastic sleeve: 0.25 to 2.5 mm
2
/AWG: 24 to 13
*** See note on ferrules
Note
Ferrules
You can achieve optimal results with respect to a high
-quality and durable electrical connection and maximum conductor
extraction forces at the sam
e time by using crimping dies preferably with smooth surfaces. Options include rectangular and
trapezoidal crimping cross
-sections.
Due to the large number of crimping dies used in the industry, we can recommend others on request.
Crimping dies with a
pronounced wave profile are not permitted in the product.
6 Maintenance and repair
The product is maintenance-free. Repairs to the product may only be carried out by the manufacturer.
WARNING
Electromagnetic interference
There is no protection against electromagnetic interference when the control cabinet door is open. The following must be
observed when working inside the control cabinet:
• Turn off mobile phones, radio devices and other devices with strong electromagnetic fields.
The following must be observed when working in hazardous areas
For applications in potentially explosive atmospheres, you must observe the guidelines specified in DIN EN IEC 60079-17
when performing functional checks.
WARNING
Explosion
Devices in hazardous areas require special periodic inspection and testing:
• Only qualified personnel are permitted to perform maintenance and repairs.
• The specific procedure and prescribed methods must be followed.
WARNING
Danger to the system
Fail-safe systems require special periodic inspection and testing:
• Only qualified personnel are permitted to perform maintenance and repairs.
• The specific procedure and prescribed methods must be followed.
