Siemens SIMATIC ET 200S - 2 Parameters

2AI U HF analog electronic module (6ES7134-4LB02-0AB0)
Manual, 04/2007, A5E01076007-01
13
Parameters
2
2.1 Parameters
Table 2-1 Parameters for analog input module
2AI U HF Range of values Default setting Applicability
Group diagnostics (parameter
assignment error, internal error)
• Disable
• Enable
Disable Module
Diagnostics: Overflow/underflow
• Disable
• Enable
Disable Module
Smoothing
1
• None
• Weak
• Medium
• Strong
None Channel
Type/range of measurement
• Deactivated
• ±5 V
• ±10 V
• 1 to 5 V
±10 V Channel
Interference frequency
suppression
1
• Disable
• Enable
Disable Module
Diagnostics: Wire break
2
• Disable
• Enable
Disable Channel
1
Not with isochronous mode
2
Only in the measuring range 1 V to 5 V
