Properties
1.1 2AI U HF analog electronic module (6ES7134-4LB02-0AB0)
2AI U HF analog electronic module (6ES7134-4LB02-0AB0)
Manual, 04/2007, A5E01076007-01
9
2AI U HF technical data (6ES7134-4LB02-0AB0)
Dimensions and weight
Width (mm) 15
Weight Approx. 45 g
Module-specific data
Supports isochronous operation
1
Yes
Supports I&M functions Yes
Number of inputs 2
Cable length
• Shielded
Max. 200 m
Parameter length 12 bytes
Address space 4 bytes
Analog value representation S5 and S7 format
1
Supported if no interference frequency suppression or smoothing is configured.
Voltages, currents, potentials
Rated load voltage L+ (from the power module) 24 VDC
• Reverse polarity protection
Yes
• Supply of the transmitters
No
Electrical isolation
• Between the channels and backplane bus
Yes
• Between the channels and load voltage L+
Yes
• Between the channels
No
Permissible potential difference
• Between channels (U
CM
)
140 VDC / 100 VAC
• Between M
ANA
and the central grounding point
(U
iso
)
75 V DC, 60 V AC
Insulation tested 500 VDC
Current consumption
• From load voltage L+
Max. 55 mA
Power dissipation of the module Typically 0.85 W
Status, interrupts, diagnostics
Diagnostics function
• Group error
Red "SF" LED
• Diagnostic functions readable
Yes
• Hadware interrupts
2
Configurable, violation of upper and lower limits
2
Hardware interrupts are only sent if the process interrupt mechanism is not overloaded.
