Compact Operating Instructions
1.6 Affixing Labeling Strips for Function Keys and Softkeys
SIMATIC HMI IPC477C / HMI IPC477C PRO
10 Compact Operating Instructions, 10/2010, A5E02368072-02
① Insert strips, vertical key rows
② Insert strips, horizontal key rows
Figure 1-2 15" touch screen device: Device rear with labeling strips
