Compact Operating Instructions
1.3 Components of the Product
SIMATIC HMI IPC477C / HMI IPC477C PRO
6 Compact Operating Instructions, 10/2010, A5E02368072-02
6. Check the contents of the package for completeness and transportation damage. Check
for completeness using the enclosed scope of delivery list.
7. Should the contents of the package be incomplete or damaged, please inform the
responsible supply service immediately and fax us the enclosed form "SIMATIC IPC/PG
quality control report".
WARNING
Make sure that a damaged device is not installed nor put into operation.
8. Note the identification information (see chapter "Identification data of the device").
Notes on display
A small number of faults in the display is unavoidable.
Bad pixels Permissible number
Permanently bright and permanently dark pixels ≤ 12
Permanently bright, green pixels ≤ 5
1.3 Components of the Product
Scope of delivery for SIMATIC HMI IPC477C
Numbe
r
Name Description
1 SIMATIC HMI IPC477C
1 Documentation and Drivers CD/DVD Contains the documentation and the hardware
drivers.
1 Operating instructions (compact)
SIMATIC HMI IPC 477C / HMI IPC477C
PRO
Printed copy in German and English of
Operating Instructions (compact).
6 Clamp Mounting clamp for SIMATIC HMI IPC477C.
1 DC power plug Only supply variant with 24 V DC power supply.
