Compact Operating Instructions
1.7 Installing/Mounting
SIMATIC HMI IPC477C / HMI IPC477C PRO
16 Compact Operating Instructions, 10/2010, A5E02368072-02
Rack mounting
Steps for fastening the device with screws
1. Follow the installation instructions.
2. Carefully drill the respective holes in the control unit at the designed location from the rear.
3. Working from the front, insert the device into the 19" rack.
4. Secure the control unit by inserting suitable screws through the holes and attaching nuts.
Swivel arm mounting
Steps for fastening the device with screws
1. Follow the installation instructions.
2. Carefully drill the respective holes in the control unit at the designed location from the rear.
3. Working from the front, place the device onto the swivel arm.
4. Secure the control unit by inserting suitable screws through the holes and attaching nuts.
Control cabinet installation
Steps for fastening the device with screws
1. Follow the installation instructions.
2. Drill suitable holes at the prepared installation cut-out in accordance with the specifications for L4
and L5, as shown at the dimensions in the mounting cut-out
3. Carefully drill the respective holes in the control unit at the designed location from the rear.
4. Working from the front, insert the device into the mounting cut-out.
5. Secure the control unit by inserting suitable screws through the holes and attaching nuts.
