11-2
TP27, TP37 Equipment Manual
Release 01/00
System Settings
Operating mode:
Display message:
Message logging:
Buffer overflow warning:
Date:
Time:
Help
ESC
Figure 11-2 System Settings standard screen for TP27-10
System Settings
Operating mode:
Display message:
Message logging:
Buffer overflow warning:
Date:
Time:
Help
ESC
Figure 11-3 System Settings standard screen for TP37 and TP27-10
Operating mode Set one of the following operating modes for
the Touch Panel:
Online
Offline
Transfer (Serial MPI)
Display message For a description, refer to chapter 6
Message logging For a description, refer to chapter 6
Purpose of
operating elements
S
y
stem Settin
g
s
