13-7
TP27, TP37 Equipment Manual
Release 01/00
SERIAL
DOWNLOAD
BOOT
CONFIGURATION
M P I D O W N L O A D
187.5 kBaud
2
FF
FF
MPI Baud Rate:
MPI OP Station Address:
Tel.:
Download Address:
Figure 13-4 Touch Panel in MPI Download mode
A fault occurring during commissioning or operation is normally displayed on
the Touch Panel by means of a system message.
Appendix C of this manual contains a list of some of the most important sys-
tem messages and explanations on how to eliminate them.
The operating data of the Touch Panel (tag values, message buffer) is stored in
a buffered SRAM and retained even in the event of a power failure. Operating
data is not lost if the power supply is turned off or fails.
Fault diagnosis
Data backup
Commissioning
