A-1
TP27, TP37 Equipment Manual
Release 01/00
Technical Data
Housing TP27-6 TP27-10 TP37
External dimensions W x H x T (mm)
without option
212 x 156 x 69 335 x 275 x 78 335 x 275 x 128
Mounting cutout W x H (mm) 203
+1
x 147
+1
310
+1
x 248
+1
Mounting depth (mm) without option 65 73 123
Degree of protection
S Front panel
S Rear panel
IP65
IP20
Weight approx. (kg) without option 1.5 5 7
Processor TP27-6 TP27-10 TP37
Type 80486 Pentium
Clock frequency (MHz) 33 100
Memory TP27-6 TP27-10 TP37
Flash (MB) 1 2
DRAM (MB) 2 8
SRAM, battery–backed (KB) 128 128
Memory card
S Slot A
S Slot B
–
For memory card !1 MB
Not used
For memory card
!1 MB
A
