When a message line has been configured it is always displayed, regardless of
the screen selected. Only the latest message is displayed in the message line.
Messages in the configured message window contain additional information on
the message, such as message number and date/time the message arrived. The
alarm message window has extra buttons.
Alarm message window:
The alarm message window (figure 6-1) automatically appears whenever an
alarm message is issued.
0000048 11:34:02 27.03.97 2
Boiler 25: Temperature 156 degrees
Summon Shift Engineer. Tel.: 9456
Message number Date
Time
Number of unacknowledged
messages (TP37 only)
Process value
ACK HELP
ESC
Figure 6-1 Alarm message window (example)
The buttons in the alarm message window have the following significance:
Button Function Purpose
ACK
Acknowledge alarm
message
When an alarm message is acknowl-
edged, the alarm message window
disappears if no other alarm mes-
sages are waiting.
HELP
Display help text Call help text concerning the alarm
message, if configured.
ESC
Cancel Set the alarm message window to
the background
