8-14
TP27, TP37 Equipment Manual
Release 01/00
Proceed as follows to load a data record from a data medium in the Touch
Panel main memory:
Step Action
1 Touch the Recipe field in standard screen Selective Data Record
Transmission.
Select a recipe for the data record to be loaded from the selection
window.
2 Touch the Data Medium field.
Select the data medium from which to load the data record from
the selection window .
3 Select the name of the data record to be loaded into the main
memory of the Touch Panel (see Editing a data record, Step 3,
Page 8-9).
4 Touch the button
Proceed as follows to save a data record in the main memory of the Touch
Panel on a data medium:
Step Action
1 Touch the Recipe field in standard screen Selective Data Record
Transmission.
Select the recipe for the data record to be saved from the selection
window.
2 Touch the Data Medium field.
Select the data medium on which the data record is to be saved
from the selection window.
3 Select the name of the data record to be save (see Editing a data
record, Step 3, Page 8-9).
4 Touch the button
Data medium ³
Touch Panel
Touch Panel ³
Data Medium
Recipes
