Error display
Error type
(BF)
Error location
(SF/BF)
Cause of the problem Measure
1 01 to 63 (slot) Communication interruption
Displays the first slot at which no I/O module
is recognized.
● Missing I/O module during POWER ON or
several I/O modules are missing during
operation.
● Interruptions at the rear panel bus
● Short-circuit at the rear panel bus ("01" is
output as the slot)
● Termination module missing
If the termination module is missing, the
number of inserted I/O modules + 1 is
output (if there is no set configuration)
Check the configuration of the
ET 200S.
2 01 to 63 (slot) Termination module not recognized
This error type is output if there is a set
configuration and the slot at which an I/O
module is no longer recognized is equal to
(number of modules of the set configuration
+1).
Install the termination module.
3 01 to 63 (slot) I/O module
The configured structure of the ET 200S does
not match the actual structure of the ET 200S.
The first slot that displays a configuration
error (missing module, incorrect module
module fault) is displayed.
This error is only output if the parameter
"Operation at preset <> actual configuration"
is locked.
Check the structure or the
configuration of the ET 200S, whether
a module is missing or defective, or
whether an unconfigured module has
been inserted.
The following errors can only occur if you have configured the ET 200S at a master from a different supplier or by using the
GSD file:
Error type
(BF)
Error location,
error code
(SF/BF)
Cause of the problem Measures
01 Configuration error at the option handling
Option handling has been configured but no
power module was configured for options
handling.
4
02 to 63 (slot) Option handling has been configured but
more than one power module was configured
for options handling. The slot of the second
power module that has option handling is
displayed.
Change the configuration.
01 General parameter assignment error
The number of module parameter blocks in
the parameter assignment telegram does not
agree with the number of identifiers in the
configuration telegram.
02 The maximum address area (inputs and
outputs) of the interface module has been
exceeded.
5
1
03 Incorrect structure of the parameter
assignment telegram.
Correct the configuration.
1
You prevent this error when configuration is carried out with STEP 7 and it is only possible if other configuration tools
are used.
