Functions
3.1 Cycle synchronization
IM151-1 HIGH FEATURE interface module (6ES7151-1BA02-0AB0)
22 Manual, 03/2008, A5E01075975-02
3.1.2 Assigning the parameters for cycle Synchronization on the PROFIBUS DP
Procedure
1. CPU settings:
"Object properties" of the CPU > Register "Cycle synchronization alarms"
– CPU - Set cycle synchronization alarm
– Select the DP master system being used
– Select the desired sub-process image
2% PV
0HPRU\ ,QWHUUXSWV ,QWHUUXSWV &\FOLFLQWHUUXSWV 'LDJQRVWLFVFORFN
7LPHRIGD\
LQWHUUXSWV
*HQHUDO
LQIRUPDWLRQ
6WDUWXS &ORFNHGLQWHUUXSWV &\FOHFORFNPHPRU\ 5HWHQWLYLW\
3ULRULW\
'3PDVWHU
V\VWHPQR
3DUWLDOSURFHVV
LPDJHVHJ
7LPHODJ
'HIDXOW
Figure 3-1 Dialog box cycle synchronization alarms
