Functions
3.1 Cycle synchronization
IM151-1 HIGH FEATURE interface module (6ES7151-1BA02-0AB0)
Manual, 03/2008, A5E01075975-02
23
2. DP master system settings:
DP master "Object properties" > "General" tab > "Properties" button > "Parameter" tab >
"Properties" button > "Network settings" tab > "Options" button
– Activate constant bus cycle time on the DP master system
– Set the length of the constant bus DP cycle (max. 32 ms)
– Set "Times Ti and To identical for all slaves" (effects a synchronization of the I/O data
of the various DP slaves)
– Times Ti and To can be set separately. Recommendation: Accept the standard
settings for Ti and To.
 PV PV

 PV PV
 PV PV
&RQVWDQWEXV
F\FOHWLPH
1HWZRUNVWDWLRQV &DEOHV
$FWLYDWHHTXLGLVWDQWEXVF\FOH
2SWLPL]H'3F\FOHDQGLIQHF7L7R
&DOFXODWHDJDLQ
1XPEHURI3*V23V7'VHWFRQWKH352),%86
&RQILJXUHG 7RWDO
(TXLGLVWDQW'3F\FOH
PLQ PVPD[ PV
7LPHEDVH
'HWDLOV
6ODYHV\QFKURQL]DWLRQ
7LPHV7LDQG7RLGHQWLFDOIRUDOOVODYHV
LIQRW6HWLQ3URSHUWLHV6ODYHV
7LPH7LUHDGSURFHVVYDOXHV
PLQ PVPD[ PV
7LPH7LUHDGSURFHVVYDOXHV
PLQ PVPD[ PV
7LPHEDVH
7LPHEDVH
Figure 3-2 Dialog box options
Note
With the "Calculate again" button you can calculate a value for the constant buy DP
cycle from STEP 7 that takes into account the current PROFIBUS DP configuration.
This value is then automatically entered in the "Equidistant DP cycle", "Time Ti (...),"
and "Time To (...)" boxes.
