SIMATIC IPC547J
24 A5E51584606-AA , 01/2022
Operation with the SIMATIC Management Agent
In order to integrate the IPC bundles into the plant managed with the SIMATIC Management Console (SMMC), you can install
or activate the SIMATIC Management Agent (SMA) during the initial commissioning or system restore.
You can choose whether or not to use the SMA in this dialog:
Initial situation
Use
A1 Image (Windows operating system only)
A2 Image (incl. PCS 7 software), if included in the
scope of delivery
Yes
The SMA corresponding to the PCS 7 version is
installed and the associated "SIMATIC Management
Agent" service is activated. After this, manage the
computer by means of the SMMC.
The "SIMATIC Management Agent" service is
activated. After this, manage the computer by means
of the SMMC.
No
-
The SMA remains on the computer with the
associated service "SIMATIC Management Agent"
disabled (this behavior matches that of the manual
PCS 7 installation).
You can also install the SMA manually via the Restore USB stick "Additional_Products\SMA" or activate it in the operating
system later on.
Additional information is available in the manual Process Control System PCS 7; SIMATIC Management Console.
Operation with DiagMonitor monitoring software
Installing DiagMonitor
If your device uses the "A1 image" (see "Scope of delivery of the software (Page 17)"), you can install the DiagMonitor
monitoring software as follows.
Procedure
1. Insert the Restore USB stick into your device.
2. Navigate to the "Additional_Products" folder and open the version-specific DiagMonitor folder.
3. Run the following files:
– DiagMonitor_Silent_Install.bat
– CM_Activate.exe
The DiagMonitor monitoring software is installed.
4. Reboot the computer.
5. Configure the SNMP service. You will find information on this in the section: "Configuring SNMP service (Page 24)".
6. Now configure the monitoring functions of DiagMonitor. You will find information on this in the section: "Configuring
monitoring functions (Page 25)".
Configuring SNMP service
SNMP service is installed on your computer. It is preset in such a way that SNMP packets are accepted from any host. You can
change this setting.
Procedure
1. Select "Computer Management > Services and Applications > Services".
2. Double-click "SNMP Service'".
The "Properties" windows opens.
3. Select the "Security" tab.
