Siemens Simatic IPC647C Getting Started

Description
2.4 Status displays
SIMATIC IPC647C
12 Getting Started, 12/2010, A5E02669344-02
Front status displays
OFF
 No connection
 No data traffic
ETHERNET 1 * ETHERNET status
display
GREEN Data traffic
OFF
 No connection
 No data traffic
ETHERNET 2 * ETHERNET status
display
GREEN Data traffic
OFF
 No connection
 No data traffic
PROFIBUS/MPI
(optional)
Display of the
communication status to
S7 or PROFIBUS
GREEN Data traffic
OFF
 CP not available
 CP disabled
 No error, communication
established
 Charging in progress
 CP 1616 driver not installed
 CP in NDIS mode
Flashes
slowly
 Link status error
 IO controller: IO device cannot be
addressed
 IO controller: Duplicate IP address
Flashes
rapidly
Exception error: diagnostics via Web
or SNMP is no longer possible
SF PROFINET
(optional)
Status display for
CP 1616 onboard
AN
 Diagnostics information available
 No communication established.
OFF WATCHDOG not activated
GREEN WATCHDOG monitoring enabled
WATCHDOG WATCHDOG status
display
RED Monitoring time elapsed
OFF Internal temperature OK TEMP Internal temperature
monitoring
RED Internal temperature critical
OFF Fan speed OK FAN Fan status (only with
active SOM or
DiagMonitor software)
RED Fan speed too low
OFF RAID is OK
One RED HDD1 or HDD2 not OK
Both RED RAID not OK
(for information on locating the hard
disk, refer to the section)
HDD1 ALARM
HDD2 ALARM
Hard disk alarm in
conjunction with RAID
and monitoring software
Both flash RAID is synchronized
All displays are lit Error in early BIOS Post All lit CPU startup failure
Error in early POST
* LAN interfaces are numbered on the enclosure to provide unique identification. The numbering by
the operating system may deviate from this.
