Dimension drawings
8.2 Dimensional drawing for the use of telescopic rails
SIMATIC IPC647C
36 Getting Started, 12/2010, A5E02669344-02
8.2 Dimensional drawing for the use of telescopic rails
Below you will find the dimensions of the telescopic rails from the Rittal company:
● Type RP 3659.180 for 600 mm cabinet
● Type RP 3659.190 for 800 mm cabinet
8QLWVRI
PHDVXUHPHQW
PP
,QFK
34,83 100 100 100
44,4
3.97 3.973.97
1.37
1.75
Figure 8-2 Dimensional drawing for the use of telescopic rails
