Siemens SIMATIC IPC677D - Overview; 1.1 Product description

SIMATIC IPC627D/827D/677D
A5E38896022-AC, 11/2017
9
Installing Windows
Supplement to section 7.5.4 of the operating instructions.
Partitions in the delivery state of Windows 10
The following information applies to data storage media ≥ 200 GB. The partitions are fixed and cannot be changed during
the installation.
Partition
Name
Size
File system
First
Boot
260 MB
FAT32
Second
MSR
128 MB
None
Third
System
160 GB
NTFS, not compressed
Fourth WinRE 500 MB NTFS, not compressed
Fifth
Data
Remainder
NTFS, not compressed
Restoring the delivery state
Supplement to section 7.5.1 of the operating instructions.
Extended options of the Restore DVD of Windows 10
Note
Set the desir
ed boot mode in BIOS Setup.
We recommend that you restore Windows 10 in UEFI mode.
You can restore Windows 10 Enterprise 2016 LTSB in the following two boot modes.
●
UEFI mode (GPT volume):
To support new features, such as TPM 2.0, Secure Boot and volumes larger than 2 TB, the operating system must be
restored in the way that it boots in UEFI mode. To do this, the Restore DVD or USB stick must be booted in UEFI mode.
The target system is then set up with a GPT volume and boots in UEFI mode.
●
Legacy mode (MBR volume):
To support extensions and functions, such as older PCI(e) cards and older software products, the operating system must
be restored to boot in Legacy mode. To do this, the Restore DVD or USB stick must be booted in Legacy mode.
The target system is then set up with an MBR volume and boots in Legacy mode.
Selecting the restore scope of Windows 10 Enterprise 2015 LTSB and Windows 10 Enterprise 2016 LTSB:
●
"Factory settings" option:
Use this option if you want to restore the factory settings of the operating system with the installed device drivers and the
SIEMENS software products.
●
"Administrator Basic" option:
Use this option if you only want to restore the operating system without additional device drivers and without SIEMENS
software products.
