Configuration and operation
4.4 SNMP
CP 1542SP-1, CP 1542SP-1 IRC, CP 1543SP-1
Operating Instructions, 01/2017, C79000-G8976-C426-03
45
SNMP
"SNMP" parameter group
● "
" parameter group
Releases the function of the SNMP agent on the CP.
Note
If the security functions are enabled for the CP
1543SP-1 you will find the parameter group
Scope of performance of the CPs
The CPs support the following SNMP version:
●
CP 1542SP-1, CP 1542SP-1 IRC
– SNMPv1
●
– SNMPv1
– SNMPv3 (with activated Security functions)
Traps are not supported by the CP.
You will find detailed information about the supported functions in the section Diagnostics
with SNMP (Page 100).
Telecontrol communication (CP 1542SP-1 IRC)
4.5.1
Configuration
Data points for telecontrol communication
No program blocks need to be programmed for the CP 1542SP-1 IRC to transfer user data
between the station and communications partner.
The data areas in the memory of the CPU intended for communication with the partner are
configured data point-related on the CP. Each data point is linked to a PLC tag or element in
a data block on the CPU.
The individual data points can be transferred to the control system and processed there.
To transfer the process data and for some options of the parameter groups "Partner stations"
and "Communication with the CPU" configured data points are required.
For further information, refer to section Data point configuration (Page 57).
