Dehumidification : _ _ _
Vibrator : _ _ _
Specimens : _ _ _
U.V. lamp : _ _ _
Water recharge: : _ _ _
Not used: : _ _ _
Not used: : _ _ _
SP. hum. CTRL. : _ _ _
Aux 1: : _ _ _
Aux 2: : _ _ _
Aux 3: : _ _ _
Aux 4: : _ _ _
Aux 5: : _ _ _
Aux 6: : _ _ _
Aux 7: : _ _ _
Aux 8: : _ _ _
V3
V4
V5
V6
Program mode : _ _ _
N° of segments : _ _ _
Init. segment : _ _ _
Current segment : _ _ _
Total repetit : _ _ _
Curr. tot. repet : _ _ _
Time from init. cycle
hh: mm: ss
_ _ _ _ _: _ _ _: _ _ _:
Time from init. segm.
hh: mm: ss
_ _ _ _ _: _ _ _: _ _ _:
V7
V8
This indicates whether the chamber is
carrying out a cycle (ON) or not (OFF)
Total number of set segments
Number of the segment starting the cycle
that the chamber is carrying out
Current number of the segment of the
cycle that the chamber has reached.
Number of cycle repetitions the chamber
has to carry out
Current number of cycle repetitions (that
the chamber has carried out)
Time that has passed from the beginning
of the current cycle
Time to end segment
hh: mm: ss
_ _ _ _ _: _ _ _: _ _ _:
V9
Time that still has to pass before the end of
the current segment (only for maintenance
segments, for the other types of segments
the value is always equal to 0).
The time is indicated in hours: minutes:
seconds of the cycle or the segment.
Time that has passed from the beginning
of the current segment
Dedicated contact 1
Dedicated contact 2
Dedicated contact 3
Dedicated contact 4
In some versions of the programme the writing
of these fields are replaced by:
Dedicated contact 5
Dedicated contact 6
Dedicated contact 7
