Technical specifications
CPU 1513R-1 PN (6ES7513-1RL00-0AB0)
38 Equipment Manual, 05/2021, A5E42009333-AC
Article number
6ES7513-1RL00-0AB0
• LLDP
Yes
Web server
•
HTTP
No
•
HTTPS
No
OPC UA
• OPC UA Client
No
• OPC UA Server
No
Further protocols
• MODBUS
Yes; MODBUS TCP
Isochronous mode
Equidistance
No
S7 message functions
Number of login stations for message func-
tions, max.
32
Program alarms
Yes
Number of configurable program messages,
max.
5 000; Program messages are generated by the
"Program_Alarm" block, ProDiag or GRAPH
Number of loadable program messages in RUN,
max.
2 500
Number of simultaneously active program
alarms
• Number of program alarms
300
• Number of alarms for system diagnostics
100
Test commissioning functions
Joint commission (Team Engineering)
No
Status block
Yes; up to 8 simultaneously
Single step
No
Number of breakpoints
8; Breakpoints are only supported in RUN-Solo
status
Status/control
• Status/control variable
Yes
• Variables
Inputs/outputs, memory bits, DBs, distributed
I/Os, timers, counters
•
Number of variables, max.
–
of which status variables, max.
200; per job
–
of which control variables, max.
200; per job
Forcing
• Forcing
Yes
• Forcing, variables
Peripheral inputs/outputs
• Number of variables, max.
200
