3.2.2 Configuration of project 2
Preparation
Open another instance of the TIA Portal configuration software and create a new
project.
Implementing the devices
Via the project navigation, insert a S7-1500 CPU (here CPU 1511-1 PN). It gets the
name “PLC_2”.
Again, in the “Devices & networks” overview, add a PROFINET interface module
(here IM 155-6 PN ST). In terms of structure and configuration (IP address and
device name), this peripheral station is identical to that in Chapter 3.2.1. Also, you
can copy the already configured ET 200SP from project 1. Thus, you can avoid the
configuration of the peripheral station.
Linking the devices
To set up an automation system, the individual hardware components must be
configured, parameterized and connected to each other. Use the device and
network view to do this.
Proceed as follows:
1. Select CPU 1511-1 PN in the project tree and open its folder.
2. Open the device view of the CPU by double clicking “Device configuration”.
3. In the graphical view, select the CPU interface to be networked. The properties
of the selected interface are displayed in the inspector window.
