Primer: S7-300 Programmable Controller, Quick Start
C79000-G7076-C500-01
Program an organization block (OB1)
and a function (FC1) for the TLIGHT
sample program.
The table below shows you how to create the required function:
Step Procedure Result
1.
Open the TLIGHT project in the SIMATIC
Manager with the menu command File → Open
→ Project ....
The project window for the TLIGHT sample
program is opened offline.
2.
Open the containers of the TLIGHT project
down to the lowest level by clicking on “+” and
select the “Blocks” container.
The OB1 stored in the “Blocks” container is
displayed offline.
3.
Insert a function with the name FC1 using the
menu command Insert → S7 Block → FC.
In the dialog box which then appears, select the
programming language you require (STL, LAD,
or FBD) and confirm with “OK”.
FC1 and OB1 are displayed offline in the project
window of the SIMATIC Manager.
Since we don’t know whether you
prefer to program in STL, LAD, or
FBD, we’ll just show you both
methods.
How Do You
Proceed?
Programming Logic Blocks with STEP 7
How Do You Create the Required Blocks?

Siemens SIMATIC S7-300 Module data Specifications

General

Series	S7-300
Manufacturer	Siemens
Protection Class	IP20
System	SIMATIC S7-300
Digital Inputs	Varies by module
Digital Outputs	Varies by module
Analog Inputs	Varies by module
Analog Outputs	Varies by module
Central Processing Unit	Varies by CPU model
Supply Voltage	24V DC or 120/230V AC
CPU Type	Varies (e.g., CPU 312, CPU 315, etc.)
Memory	Varies by CPU model
Communication Interfaces	MPI, PROFIBUS
Programming Languages	LAD, FBD, STL, SCL, GRAPH
Operating Temperature	0°C to 60°C
Storage Temperature	-40°C to 70°C
Relative Humidity	10% to 95% (non-condensing)
