Siemens SIMOCODE pro V PB User Manual

An overview of system components
SIMOCODE pro
70 System Manual, 05/2019, A5E40507475002A/RS-AD/004
Module
Control
supply
voltage
MLFB
Diagram
Number that can be connected to
pro C
pro S
V PN
GP
pro V
PB
pro V
MR
pro V
PN
pro V
EIP
Current/voltage measuring module (UM)
Can only be mounted next to the basic unit,
otherwise like current measuring modules.
Additionally:
• Voltage measurement
• Power measurement
• Power factor (cos phi) measurement
• Phase sequence
0.3 A to 3 A
(through-hole
transformer)
2.4 A to 25 A
(through-hole
transformer)
10 A to 100 A
(through-hole
transformer)
20 A to 200 A
(through-hole
transformer)
20 A to 200 A
(bus
connection)
63 A to 630 A
(bus
connection)
— 3UF7110-1AA00-0
3UF7111-1AA00-0
3UF7112-1AA00-0
3UF7113-1AA00-0
3UF7113-1BA00-0
3UF7114-1BA00-0
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
1 (from
*E02*)
1 (from
*E02*)
1 (from
*E02*)
1 (from
*E02*)
1 (from
*E02*)
1 (from
*E02*)
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
