An overview of system components
SIMOCODE pro
System Manual, 05/2019, A5E40507475002A/RS-AD/004
71
Number that can be connected to
2nd generation current/voltage measuring
modules (UM+)
Can only be mounted below / next to the basic
unit, otherwise like current measuring modules.
In addition to current measurement:
• Voltage measurement
• Frequency measurement
• Power measurement
• Power factor (cos phi) measurement
• Phase sequence detection
• Dry-running protection for centrifugal pumps by
means of active power monitoring (DRP
device)
0.3 A to 4 A
(straight-
through
transformer)
1)
3 A to 40 A
(straight-
through
transformer)
1)
10 A to 115 A
(straight-
through
transformer)
20 A to 200 A
(straight-
through
transformer)
20 A to 200 A
(bar connection)
63 A to 630 A
(bar connection)
— 3UF7110-1AA01-0,
3UF7120-1AA01-0
(DRP)
3UF7111-1AA01-0,
3UF7121-1AA01-0
(DRP)
3UF7112-1AA01-0,
3UF7122-1AA01-0
(DRP)
3UF7113-1AA01-0,
3UF7123-1AA01-0
(TLS)
3UF7113-1BA01-0,
3UF7123-1BA01-0
(DRP)
3UF7114-1BA01-0,
3UF7124-1BA01-0
(DRP)
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
1 (from
*E15*)
1 (from
*E15*)
1 (from
*E15*)
1 (from
*E15*)
1 (from
*E15*)
1 (from
*E15*)
1
(from *
E03*)
1 (from
*E03*)
1 (from
*E03*)
1 (from
*E03*)
1 (from
*E03*)
1 (from
*E03*)
1
(from
*E10*)
1
(from
*E10*)
1
(from
*E10*)
1
(from
*E10*)
1
(from
*E10*)
1
(from
*E10*)
1
1
1
1
1
1
1)
For connecting on the line side of a current/voltage
measuring module of the 1st generation UM at the
system interface for use of voltage measurement
in isolated-neutral systems, systems with high-
impedance resistive or asymmetrical grounding,
and in single-phase systems.
