10.7 Force-ventilated motor
10.7.1 Force-ventilated motor, complete
Figure 10-2 Schematic representation of the motor, complete
Table 10-2 Motor, complete
Number Designation Number Designation
3.00 Spare parts kit, NDE bearing 8.00* Rotor, complete
4.00 Spare parts kit, DE bearing 10.00* Stator housing (with laminated core,
winding and cooling water pipe system)
55.00 Spare parts kit, speed encoder 10.35* Eyebolt
5.00* Bearing shield, DE 20.00* Terminal box
6.00* Bearing shield, NDE 99.00* Special built-on components
* On request
Spare parts
10.7 Force-ventilated motor
SIMOTICS M-1PH8 1PH818., 1PH822.
122 Operating Instructions 07/2016
