10.7.2 External fan




Figure 10-3 Spare parts for external fan (type 1PH818., 1PH822.)
Table 10-3 Spare parts for external fan
Part Description Part Description
32.00 Fan 34.31 External grill cover
34.21 Filter element * 34.33 Inside basket
* Option for type 1PH828.
10.7.3 External fan (option L75)
The external fan for option L75 can only be ordered as one part. Contact the Service Center,
if necessary.
Spare parts
10.7 Force-ventilated motor
SIMOTICS M-1PH8 1PH818., 1PH822.
Operating Instructions 07/2016 123
