Permissible minimal and maximal ambi-
ent temperature for operation
-15...60 °C (
rating plate)
To avoid condensation the drive must be continuously energized due to the applica-
tion of heat, with interruptions such that cooling to the point of condensation does not
occur.
Max. permitted conveyor temperature 80 °C
Permissible temperature range for stor-
age and transport
-25...+70 °C
Max. permissible installation height height 1000 m amsl without derating
Permissible rel. humidity 98 % (briefly 100 %)
Electromagnetic compatibility for the
standard voltage 230 / 400 V according
to IEC 60038
Interference emission EN 61000-6-3 (domestic household applications)
Interference immunity EN 61000-6-2 (industrial applications)
Harmonics current Active power factor adjustment for sinusoidal input current (PFC = Power - Factor -
controller), harmonic current in accordance with EN 61000-3-2 are guaranteed.
Max. leakage current according to the
defined networks of EN 60990
< 3.5 mA
dB(A) values
Data sheets available at Siemens
Ball bearings grease service-life (F
10h
) during standard usage approx. 40.000 h
Protection class of motor according to
EN 60034-5
IP55
* Regarding the mains connection, these devices are to be classified as category “C2” devices according to the relevant
DIN EN 61800-3. The increased requirements placed on electrical interference > 2 kHz for category “C1” devices are
complied with in addition.
For motors with the corresponding quality mark (
rating plate)
Authorization: FILE No.
E347018
UL 1004-3
UL 1004-7
Electronically Protected Motors
- Component
Assembly instructions ECblue Enclosure
L-BAL-F065-GB 1617 Index 004 Part.-No. 00702801-GB
24/28
