Supplementary system components
6.4 Controller Extension CX32
SIMOTION D4x5
100 Manual, 02/2012
General technical data
Table 6- 25 Technical data (general)
Data SIMOTION CX32
Power supply
• Rated value
• Permissible range
24 VDC
(20.4 ... 28.8 V)
Current consumption, typically
1)
800 mA
Starting current, typ. 1.6 A
Power loss 20 W
1)
With no load on inputs/outputs, no 24 V supply via DRIVE-CLiQ interfaces
Digital inputs
Table 6- 26 Digital inputs on SIMOTION CX32
Data SIMOTION CX32
Digital inputs 4
• Rated value
24 VDC
• For signal "1"
15 ... 30
• For signal "0"
2)
-3 ... +5 V
Galvanic isolation Yes, in groups of 4
1)
Current consumption typ. at High level 10 mA at 24 V
Input delay, typ. (hardware) L -> H: 50 µs
H -> L: 150 µs
1)
The reference potential is terminal M1
2)
The digital inputs are protected against polarity reversal up to -30 V
