Requirement/presence of a fan (from V4.2)
System variables can be used to evaluate:
● Whether a fan is required for the operation of the device (or not)
● Whether a fan is available (or not)
Table 2- 8 System variable fannecessary/fanexisting
System variable on the
device
States Description
fanbattery of the structfanbattery type (the system variables are of the enumfanbattery type)
MANDATORY Fan is required for operation of the device.
.fanexisting can be used to query whether a fan
is available.
Examples: D410, D445, D445-1,
D445-2 DP/PN, D455-2 DP/PN
OPTIONAL Fan can be used optionally. .fanexisting can be
used to query whether a fan is available.
Examples: D425, D435
.fannecessary
1)
NOT_MANDATORY Fan is not required for operation of the device
SINGLE A single fan is present
Examples: D410, D4x5
REDUNDANT Double fan is available
Examples: D445-1, D445-2 DP/PN,
D455-2 DP/PN
.fanexisting
1)
NOT_EXISTING No fan is present
Example: D425 without optional fan.
1)
Value is statically set to MANDATORY/SINGLE in the SIMOTION D410.
See also
SIMOTION D410 memory model (Page 33)
Properties of the user memories (Page 34)
