Commissioning (hardware)
2.5 User memory concept
SIMOTION D410
Commissioning Manual, 02/2012
43
Requirement/presence of the battery (from V4.2)
System variables can be used to evaluate:
● Whether a battery is required for the operation of the device (or not)
● Whether a battery is present (or not)
Table 2- 7 System variable batterynecessary/batteryexisting
System variable
on the device
States Description
fanbattery of the structfanbattery type (the system variables are of the enumfanbattery type)
MANDATORY Battery is required for the backup of the retain data and
the real-time clock (RTC) of the device. .batteryexisting
can be used to query whether a battery is available.
OPTIONAL The retain data and the real-time clock (RTC) are
backed up via SuperCap. A battery can be used as an
option to extend the backup time. .batteryexisting can
be used to query whether a battery is available.
Example: D4x5
OPTIONAL_RTC
1)
A battery is not required for the backup of the retain
data.
Only the real-time clock (RTC) is backed up via
SuperCap. A battery can be used as an option to
extend the backup time of the real-time clock.
.batteryexisting can be used to query whether a battery
is available.
Example: D4x5-2
.batterynecessary
NOT_MANDATORY
1)
A battery is not required for the backup of the retain
data. The real-time clock (RTC) is backed up via
SuperCap.
Example: D410
EXISTING EXISTING is only displayed when .batterynecessary is
set to:
• MANDATORY or
• OPTIONAL or
• OPTIONAL_RTC
and a battery is available.
.batteryexisting
NOT_EXISTING Battery is not available
1)
If the SuperCap is discharged, the contents of the real-time clock (RTC) are lost
