The CF card is supplied in a bootable format with the latest SIMOTION Kernel and drive
software.
The CF card is used for:
●
Backup technology packages and user data
● Update (e.g. SIMOTION firmware update)
NOTICE
Damage to the CompactFlash card from electrical fields or electrostatic discharge
The CompactFlash card is an ESD-sensitive component.
De-energize
the SIMOTION D410 device before inserting or removing the CompactFlash
card. The SIMOTION D410 is in a de-energized state when all the LEDs are OFF.
Comply with the ESD rules.
Additional information
For more information on writing to and formatting the CF card, see the
SIMOTION D410
Commissioning Manual
.
See also
System data, connection values, dimensions and weight (Page 87)
3.3 Error and status indicators
Arrangement of LED displays
The LED displays are located under the CF card plug-in slot on the SIMOTION D410 (see the
section titled Overview of operator controls and indicators (Page 35)).
Further information
For the meanings of LED statuses, see the
SIMOTION D410
Commissioning Manual.
Operation (hardware)
3.3 Error and status indicators
SIMOTION D410
Manual, 04/2014 39
