Circuit-diagram macros
EPLAN
circuit-diagram macros are available for SIMOTION D410. The macros are supported
when you create circuit diagrams.
For information on how to do this, refer to: Internet address (
http://
support.automation.siemens.com/WW/view/en/31622426).
7.4
System data, connection values, dimensions and weight
PLC and motion control performance
Table 7-1 General information about SIMOTION D410
Maximum number of axes 1 (real axis)
Minimum PROFIBUS cycle clock 2 ms (D410 DP)
Minimum PROFINET send cycle clock 0,5 ms (D410 PN)
Minimum position control/interpolator cycle
clock
2,0 ms
Table 7-2 Integrated drive control
Max. number of axes for integrated drive
control (servo/vector/
V
/
f
)
1 / 1 / 1 (alternative)
drive control based on SINAMICS S120 CU310, firmware
version V2.x
Memory
Table 7-3
Memory data
RAM (Random Access Memory) 38 MB (as of V4.2)
26 MB
(A
20 MB RAM is available for java applications with V4.1
SP2 and higher.)
RAM disk (load memory) 23 Mbyte (as of V4.3)
17 Mbytes
Retentive memory 9 KB
Persistent memory
(user data on CF card)
1-GB CF: 300 MB
Non-volatile data backup
Backup time, min.
Unlimited (maintenance-free backup)
Real-time clock, min. 5 days (maintenance-free backup)
Table 7-4 Memory for system data and its memory size
Diagnostic buffer (non-volatile) 100 messages (SIMOTION)
100 messages (SINAMICS Integrated)
Technical data
7.4 System data, connection values, dimensions and weight
SIMOTION D410
Manual, 04/2014 87
