Communication
Table 7-5
SIMOTION D410 interfaces
DRIVE-CLiQ interface 1
PROFIBUS interface 1 (D410 DP only)
●
Isochronous
● Can be configured as master or slave
PROFINET interface 1 interface with 2 ports (D410 PN only)
●
Supports PROFINET IO with IRT and RT
● Can be configured as PROFINET IO controller and/or
device
Table 7-6 Address space
Address space D410
Logical I/O address space 8 KB
Physical I/O address space
●
PROFIBUS: max. each for inputs and
outputs
● PROFINET: max. each for inputs and
outputs
1 KB (D410 DP)
1 KB (D410 PN)
Permanent process image for
BackgroundTask (I/O variables)
64 bytes
Additional configurable process image for
each cyclic task (I/O variables)
Yes
Address space for each PROFIBUS DP
station
244 Byte
Address space per SINAMICS Integrated
(PROFIBUS Integrated)
512 Byte
Address space for each PROFINET device 1400 Byte
General technical data
The SIMOTION D410 has an integrated fan.
Table 7-7
SIMOTION D410 electrical connection values
Power supply 24 V DC (permissible range: 20,4 ... 28.8 V)
Current consumption, typically
1)
Basic configuration
0.8 A
Inrush current 3,0 A
Power loss, typ. 20 W
1)
With no load on inputs/outputs, no 24 V supply via DRIVE‑CLiQ and PROFIBUS interface
Technical data
7.4 System data, connection values, dimensions and weight
SIMOTION D410
88 Manual, 04/2014
